*Input
Nominal Voltage: 400 VAC 3F
Voltage Tolerance: +20% / -25%
Frequency: 45 to 65 Hz
Soft Start: 0 - 100% in 125 sec (preset)
BY-PASS
Nominal Voltage: 400 V 3F + N (± 20%, preset)
Frequency: 50 or 60 Hz (Adjustable).
*Output
Nominal Power: 80 kvas.
Active Power: 72 kW.
Nominal Voltage: 400 V 3F ± 20% (preset)
Frequency: 50 or 60 Hz (adjustable).
Static Stability: ± 1%
Dynamic Stability: ± 5%
Voltage Distortion with Linear Load: 1% typ, 2% Max
Crest Factor (Ipeak/Irms) - EN62040-3: 3:1
Voltage Distortion with Non-Linear Load: < 3%
Overload: 110% for 60 min, 125% for 10 min, 150% for 1 min.
BATTERY
Type: VLRA AGM /GEL; NiCd for PV applications
Nominal Voltage: 384 Vdc
Residual Ripple Voltage: ± 1%
Maximum Charging Current from SPS Output (PV Inverter): 200A
*System
Dimensions (HxWxD): 888x740x1400
Weight (kg): 52
Operating Temperature: 0 to 40°C
RH: < 95% non-condensing
Color: RAL 7035
Protection Level: IP20
Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; Performance IEC EN 62040-3
