Paneles solares para caravana y camper

12V

Model SPR-E-Flex-110 SPR-E-Flex-100
Nominal Power(Pnom) 110 W 100 W
Power Tolerance +6/–3% +6/–3%
Rated Voltage (Vmpp) 18.8 V 17.1 V
Rated Current (Impp) 5.9 A 5.9 A
Open-circuit voltage (Voc) 22.8 V 21.4 V
Short-curcuit current (Isc) 6.3 A 6.3 A
Power Temp Coeffiecient –0.30%/° C –0.35%/° C
Voltage Temp Coefficient –55.8 mV/° C –58.9 mV/° C
Current Temp Coefficient 3.5 mA/° C 2.6 mA/° C
Max. System Voltage 45 V
Series Fuse Rating 15 A

Solar Cells Prime monocrystalline
25% and 23% efficiency SunPower IBC cells
Junction Box TE 1-21-2152049-1 with by-pass diode
Connectors Tyco (PV4-S)
Cables 4 mm2,12 AWG,
450 mm long
Grommets 316 Stainless Steel
Charge Controller None provided
Weight 2 kg
Panel Dimensions 1165 x 556 x 20 mm with Jbox, 2 mm w/o Jbox
